Product Advantage
Advantages of automatic patty making machine:
The fish/shrimp/meat patty machine can directly connect to the tempura and flour-coated equipment such as batter machine, flour coating machine, fryer machine and so on.
It can directly connect to food processing equipment, such as steamer and quick-freezer.
The forming machine adopts screw feeding method, and adopt special structure to reduce the crushing of materials.
The raw materials are formed at room temperature, no liquid nitrogen cooling is required, and the use cost is low.
Simple operation, one-button start, adjustable production speed (feeding, molding, etc.).
By changing the molds, it can realize the molding of products of different sizes and shapes (round, square, oval, heart, etc.).
The thickness of the product can be adjusted. The products of the same external size and different thicknesses can be adjusted by the thickness adjustment part, and the adjustment range is 5mm-18mm.
Technical Parameters
| Machine Name | Automatic patty making machine |
| Capacity | 22,000-40,000 pcs/hour according to product size |
| Material | SUS 304 |
| Mould effective width | 600 mm |
| Effective width of conveyor belt | 590 mm |
| Horizontal conveying height | 750 mm＋100 mm |
| Height of raw material inlet | 1450 mm |
| Voltage | 220/380/415/440/460V(can be customized) |
| Power | 6.9 kw |
